DZ High quality Stainless Steel filter for Cooking Oil filter

FOB Reference Price:Get Latest Price
US $1,000-10,000 / Sets | 1 Set/Sets cooking oil filter (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Semi-Automatic
Production Capacity:
High Efficiency
Place of Origin:
Henan, China (Mainland)
Brand Name:
DAZHANG
Model Number:
DZCF-5-20
Voltage:
Customized
Power(W):
0.15KW-7.5KW
Weight:
191~7010kg
Dimension(L*W*H):
900*700*120*220*350 mm
Certification:
ISO9001;CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
Dazhang Cartridge filter
Description:
Solid-liquid Separation Machine
Application:
Drinking;Food; Chemical
Theroretical flow:
3-5 t/h
Inlet/ outlet:
DN 32
Filter Precision:
0.1-60 um
Cartridge QTY:
5
Cartridge length:
20 "
Material:
Stainless Steel; PP
Connection type:
Fast assembly / Flange
Supply Ability
Supply Ability:
10000 Set/Sets per Year cooking oil filter
Packaging & Delivery
Packaging Details
wooden case
Port
shanghai
Lead Time :
25 days after payment
Product Description
Henan Dazhang High quality SS filter for Cooking Oil filter

Instruction of Cartridge filter:

Cartridge filter (also named precision filter), the housing usually is made of stainless steel. The filter uses cartridge as the filtering medium. The cartridge can be: Melt Blow Cartridge/ String Wound Cartridge/ PP Folded Cartridge/ Nylon Membrane Cartridge/ PES Cartridge/ PTFE Cartridge. A different filtering element is selected according to different filtered material and the desigened technology to reach the quality requirements. The filter precision range: 0.1-60 um; the model includes 10 inches, 20 inches, 30 inches and 40 inches; Connection ports: plug port(222 and 226) and flat port.

Theoretical flow T/hCartridge QTYCartridge lengthInlet/ OutletConnection TypeDimension
0.3-0.5110"DN20Fast Assembly/ Flange600*40080*100*220
0.6-120"800*650
1-1.530"1050*900
1-1.5310"DN25650*450120*200*320
1.5-320"900*700
3-4.530"DN321150*950
1.5-2.5510"650*450120*220*350
3-520"900*700
5-730"DN401150*950
2-3.5710"950*700150*250*400
4-720"DN501200*950
7-1030"1450*1200
6-8920"1000*700150*300*450
8-1230"1250*950
12-1540"1500*1200

Working Principle of Cartridge filter:

The liquid will be fed into the filter from the inlet, then go through the cartridge from external side to inner side, then discharge from outlet. While the filtering, impurities will be trapped by the cartridge, so that realize filtering effect.


Features of Cartridge filter:

  • Even distributed apertures ensure high filtering precision
  • High cleanliness of cartridge material makes no secondary pollution
  • Good chemical stability: Resists alkaline, acid and chemical solvents.
  • Cost saving, low running cost, easy clean and the cartridge can be change.
Our Services

Pre-sale Serive

Our technical support team which have the professional knowledge level will help you to solve the problems that you meet in the using process of the solid-liquid equipments.

Services during the sale

In the process of the clients buying the products, we will provide clients the satisfactory and considerate service through a series of rigorous service style. We respect clients and always devote ourselves to improving the total of clients: help clients to draft solving plans.

After-sales service

Dazhang Filter Equipment Co., Ltd insists on providing clients with overall solutions from equipment recommendation to debugging and installation, worker training, technical support and maintenance. Our mission is woking through professional consulation, exquisite thchnical support and standard solution in order to constantly meet your neds, and finally achieve satisfactory results.

Technological support

Dazhang Group has been largely adopting new technologies, new techniques and high-tech equipments. And Dazhang Group also has strict and effective quality control system. We have obtained Iso9001 quality system certificate.

Packaging & Shipping



Technical Advantage

    1.Dazhang Filter Equipment is the biggest factory in north-central of China, and we have the biggest injection molding machine with 4000 tons.

    2.The oil cylinder seat, pressing plate and thrust plate are formed by carbon dioxide prodection welding.

    3.Dazhang self-developed filter press with the biggest filter area of 1000m2 goes well in Vietnam.

    4.The main beam of Dazhang filter press is designed by adopting welded box contruction, and manufactured by making use of submerged arc auto welding technology.

    5.The chain cover which is independently developed by Dazhang has the characteristic of high hardness and anti-corrosion.

    6.All the spare parts that need painted are dealed with high speed centrifugal ball blast descaling and iron scale. After painting MIO epoxy build primer, paint acrylic polyurethane coating directly to make it have the best adhestion. It can save hundreds tons of putty every year, thus not only reduce the cost, but also protect the enviroment. More important, it improves the adhesion of the paint and antisepsis class of the filter press.

Customer Pictures

customer visit.jpg

Company Information

    Henan Dazhang Filter Equipment Co., Ltd. is a professional filter press manufactures. It has three subsidiary corporations in Shanghai and Yuzhou. Now Henan Dazhang is the biggest filter press base in the center of China. We are specialized in designing, producing and selling filter presses and other related equipment. Our products mainly include more than 6series related hundreds of good sellers, such as Automatic Membrane Filter Presses, Automatic Chamber/Racessed Filter Presses, Hydraulic/Mechanical/Manual Filter Presses, Special Filter Presses, Filter Plates(including CGR Gasketed Filte Plates),Belt Filter Presses, Bag Filters ect. In order to meet different filtration needs of customers, we have been constantly developing and improving our prduct technology, quality, process automation and after-sales services. Our unremitting efforts for years have bought us great trust from customers and our products enjoy fast sales abroad.

    Our products find their extensive applications in the fields of petroleum, chemical, pharmacy, sugar refinery, food stuff, coal washing, oiling, printing and dyeing, ceramaic, mining and metallurgy, sewage disposal and so on. With good quality, our products are not only widely welcome in China, but also successfully exported to many countries,such as America, the EU, Russia, Australia etc. Many of our customers are lieted on Fortune Global 500 Companies.


FAQ



1). Are you filter press manufuacturer?

    Yes, we are the company whichis the joint of trade and industry, and we can also provide sample test,

equipment manufacture,after-sale serviece,etc.

2). Which country have your products been exported?

    Many country, such as Australia, EU, America and so on. And our company has agencies in Vietnam.

3). What industry application of this product?

    Many industries, such as chemical, food, medicine, sludge treatment and so on.

4). How many about your MOQ?

    1 Set.

5). What is the voltage/phase for this machine ?

    220V 50Hz 3Phs, 380V 50Hz 3Phs and 415V 50Hz 3Phs,also can made as the clients need.

6). What is the Mode of transportation ?

    LCL and FCL by ship ,By Express (DHL,TNT, Fedex etc) ,By air

7). How long can we get the goods?

    we usually delivery in 3-5 working days, we will inform you shipping time based on your seaport.

8). What about Payment term?

    T/T(Telegraphic Transfer ) --30% as prepayment by T/T, after seen the copy of the B/L sent by fax,

 the balance of 70% should be effected . Western Union ,L/C ,Trade Assurance,Etc.
